vs
Light and Motion Li-ion Ultra 13w HID: 674g (5 to 6 hours burn time)# of Tests: 6
Test #1:
Location: 4m x 4m white painted room.
Method: Aimed each light at the white ceiling and measured the total reflected light with the light meter fixed in the middle of room.
Brighter-Lights.com Revelation-3 = 58 Lux
Light and Motion 13w HID = 36 lux
_______________________________________
Test #2:
Location: 4m x 4m white painted room.
Method: Aimed center spot of each beam at light meter at 2m distance.
Brighter-Lights.com Revelation-3 = 4243 Lux
Light and Motion 13w HID = 2114 Lux
_______________________________________
Test #3:
Location: Concrete enclosed grass lawn (full effect of reflected light)
Method: Aimed each light at marker at 12m distance.
Click for larger image...
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEgI2cbFXtH2GhI7G4NSLiBn-EwLgYRuSejNB53_Yb0RlDMRTa3a6krv08mWNAIPsDAHW3f11MnbsIfddGdg42Qh3a0slNBYT1NnX_J8FEb15e2ENcll9hYV3W7u9aSCacEAgjjRGuk9Qg/s400/spotl.jpg)
_______________________________________
Test #4:
Location: Grass covered bushveld road.
Method: Aimed the center spot of each beam at a white reflector at 40m distance.
Camera settings:
ISO 200
F4.0
3.2 Seconds
Daylight white balance
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEhtjnsxCXtP2chXq7-ZMTWLEzSrNhhQXWLsjOw8YwE4EQ9sciSJNL2Su8E6yATze-hishiugjKyv8O8YhjsOO_7xQL2xm_kCE_dFGQmmtDHafXgc6K-u3TOSONy-EInB7cbJOPmOCKSPQ/s400/Untitled-2.jpg)
______________________________________
Test #5:
Location: Straight road with riverine forest.
Method: Aimed the center spot of each beam at 60m distance, light meter set up at 20m in middle of road, markers at 40m and 75m.
Brighter-Lights.com Revelation-3 LED = 46 Lux
Light and Motion 13w HID = 15 Lux
Click for larger image...
Overall light, difficult to see detail at 40m to 75m. (see next photo)
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEhazDlo-0zu61QrEGaKq9vG4ihw-s0wwBUMhO05rCSnZsFR84Nc7ZtjekCKMDh3eFEoBocx_ILSvKLUrCRB4-8iHaLEFlzdBZMXuSk8srN_pW1EKQBd7qJ62J6OtgxwHduh6zxkFDA0eA/s400/lm_vs_rev3_high_beam.jpg)
Photo below is a cropped version to see more detail from 30 to 75m.
Click for larger version...
The Revelation-3 'blinds' the Light and Motion at 40m to 75m distance...!
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEiG_ZCkvsW7iz3JH9nUOtVWgWUsGaLPjRokYxBZMUWXQ-BiHfQC_rz_1wy6uJIzGAv5u2A2aFtz0bT-SkinD8Hz2IkbFk2KdvY3cPGD0mYuHxhlA4dbwjutq-radlY1gtY59F2fTbVM8Q/s400/rev-3-vs-l&m-zoom.jpg)
______________________________________
Test #6:
Location: Same as above, dim beam.
Light and Motion Li-ion Ultra 13w HID: low beam = 6 hours
Brighter-Lights.com Revelation-3: level 4 of 5 = 11 hours
Click for larger image...
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEh9SW_79n-6LpQwULARXaGeqGsAisOopFg5m8g_Ytmnztj7NT6rnY2KmreKn_r204lrNETh_iN9CTHeNbUOLNKt5w4Xe1V8ctjia5hoaWeJq8_R4e78D2vbIAkIQGzZvuLmyooUqV2WbQ/s400/lm_vs_rev3_low_beam.jpg)
Conclusion:
From the first moment the 13w HID appeared much dimmer than the Revelation-3 LED.
Both systems weigh about the same, but it's clear that the Revelation-3 LED kills the 13w HID in every respect.
